20ft GP /40ft GP /40ft HC ISO Blue Painted dry cargo shipping container

FOB Reference Price:Get Latest Price
US $1,500-4,500 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Dry Container
Length (feet):
40'
Certification:
ISO9001
Capacity:
74CUM
External Dimensions(l x W x H)(mm):
12192mm * 2438mm * 2896mm
Internal Dimensions(l x W x H)(mm):
12032mm * 2352mm * 2698mm
Place of Origin:
Shandong, China (Mainland)
Brand Name:
DFC
Model Number:
40'HC
quality:
very good
color:
red or blue or white
stacking:
7 layer
certificate:
CCS, BV, ABS
floor:
wooden
payload:
28000kg
Packaging & Delivery
Packaging Details
one piece, export package.
2192mm * 2438mm * 2896mm
Port
Qingdao
Lead Time :
within 20 working days after receiving prepayment.

20ft GP /40ft GP /40ft HC ISO Blue Painted dry cargo shipping container





Product Description

Standard and certificate:

Containers will comply with following in their latest editions :

1) ISO/TC-104

668

-

Series 1 freight containers-Classification, external dimensions and ratings

6346

-

Coding, identification and marking for freight containers

1161

-

Specification of corner fittings for series 1 freight containers

1496/1

-

Specification and testing of series 1 freight containers.

Part 1 : General cargo containers for general purposes

830

-

Freight containers-Terminology.

6359

-

Freight containers-Consolidated data plate

2) The International Union of Railway (UIC) code 592 OR.

3) The Customs Convention on the International Transport of Goods(TIR).

4) The International Convention for Safe Containers (CSC).

5) Transportation Cargo Containers and Unit Loads Quarantine Aspects and Procedures by Commonwealth of Australia Department of Health. (TCT)

6) provide certificates from classification society (BV, ABS, GL, CCS, LR, KR).





The specifications of 40’ HC containers:



1 Dimension





External Dimensions

Internal Dimensions

Length

12,192 (0, -10) mm

12,032 (0, -10) mm

Width

2,438 (0, -5) mm

2,352 (0, -5) mm

Height

2,896 (0, -5) mm

2,698 (0, -5) mm



2 Door Opening



Width   ..................

2,340 (0, -5)

mm

Height ...................

2,585 (0, -5)

mm



3 Gooseneck Tunnel



Length ..................

3,315

mm

Width   ..................

1,029 (+3, 0)

mm

Height ...................

   120 (0, -3)

mm



4 Inside Cubic Capacity



                       76.4cu.m       2,700 cu.ft



5 Rating



Maximum Gross Weight ..............

30,480 kg

67,200 lb

Maximum Payload     .............

26,580 kg

58,600 lb

Tare Weight (±2%)     ...............

3,900 kg

8,600 lb







Applications or special features:



1. ISO standard general dry cargo steel shipping container.



2. for sea, inland, and railway transportation.



3. convenient for loading, lifting, moving.





















FAQ

 what's the max gross weight?

answer: 30480kg.

can we add our logo on the containers?

yes, you can.

can we choose the color for our containers?

yes, you can,  no extra recharge for batch quantity.

can you send our containers to port in China?

yes, we can send containers to Qingdao port, it is free.

can you help arrange "one way" ?

yes, we can,  that's will save a lot ocean freight.





Packaging & Shipping

Packaging detail: export package.

Delivery detail: within 20 working days after receiving prepayment.





Our Services

1. we can design similar products in different types according to different customize requirements.

2. arrange transportation for customers.

3. arrange "one way" transportation for "SOC" containers.

4. provide professional consultation services.
