China 20GP 40GP 40HC Cold Fresh Vegetable Refrigerator Containers Reefer Container Hot Pop

FOB Reference Price:Get Latest Price
US $13,000-17,000 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Reefer Container
Length (feet):
20'
Certification:
CSC
Capacity:
28.4CUM
External Dimensions(l x W x H)(mm):
6058mm * 2438mm * 2591mm
Internal Dimensions(l x W x H)(mm):
5456mm * 2294mm * 2273mm
Place of Origin:
Shandong, China (Mainland)
Brand Name:
DFC
Model Number:
20ft
Container outterpanel material:
CORTEN
Container inside panel material:
Dtainless steel
Container temperature range:
-30° C to + -30° C
Electrical Voltage:
380 V / 460 V
Container device:
Daikin, thermoking, Carrier
Container floor:
T shape / flat floor
Container application:
Freezing container, reefer container
Container color:
Customized
Container certification:
ISO9001
Container size:
20ft,40ft,40hc
Supply Ability
Supply Ability:
2000 Unit/Units per Month
Packaging & Delivery
Packaging Details
one piece, export package.
6058mm * 2438mm * 2591mm
Port
Qingdao
Lead Time :
within 20 working days after down payment.



China 20GP 40GP 40HC Cold Fresh Vegetable Refrigerator Containers Reefer Container  Hot Pop





keywords:refrigerator shipping container, reefer container, cooling container , vegetable shipping container,homotherm shipping container



product description

Standard and certificate:

Containers shall comply with following in their latest editions :

1) ISO/TC-104

668

-

Dimensions and ratings(1993 edition)

6346

-

Coding, identification and marking(the third edition 1995)

1161

-

Specification of corner fittings(1990 edition/Cor.1.: 1990)

1496/2

-

Specification and testing thermal containers(1996 edition)

3874

-

Freight containers, handling and securing.

6359

-

Freight containers-Consolidated data plate

2) The International Union of Railway (UIC) code 592 OR.

3) The Customs Convention on the International Transport of Goods(TIR).

4) The International Convention for Safe Containers (CSC).

5) Transportation Cargo Containers and Unit Loads Quarantine Aspects and Procedures by Commonwealth of Australia Department of Health. (TCT)

6) provide certificates from classification society (BV, ABS, GL, CCS, LR, KR).



The specifications of 20’ reefer containers:

1 Dimension



External Dimensions

Internal Dimensions

Length

6,058 ( 0, -6 ) mm

5,456 ( 0, -12 ) mm

Width

2,438 ( 0, -5 ) mm

2,273 ( 0, -10 ) mm

Height

2,591 ( 0, -5 ) mm

2,294 ( 0, -10 ) mm

2 Door Opening

Width   ..................

2,290 ( 0,-5 )

mm

Height ...................

2,264 ( 0,-5 )

mm

Cargo access height

2,221 ( 0,-5 )

mm

3 Fork Pocket

Width   ..................

360

mm

Height ...................

115

mm

Center distance .......

2,050

mm

4 Inside Cubic Capacity

                       28.4 cu.m       1,002 cu.ft

5 Rating

Maximum Gross Weight ..............

30,480 kg

67,200 lbs

Maximum Payload     .............

27,440 kg

60,500 lbs

Tare Weight           ...............

2,500 kg

5,510 lbs

Tare Weight(incl. Unit 540KG)

3,040 kg

6,700 lbs



Applications or special features:

1. ISO standard reefer container.

2. for sea, inland, and railway transportation.

3. convenient for loading, lifting, moving.




2015.4.28



 40



4012342324





Our Services

1. we can design similar products in different types according to different customize requirements.

2. arrange transportation for customers.

3. arrange "one way" transportation for "SOC" containers.

4. provide professional consultation services.
